Key Features
- Ideal for processing straight line boxes, crash lock bottom boxes, double wall boxes and CD/DVD sleeves
- Low space requirements
- Durable design
- Maintenance-free drive
- Easy format changes
- Ideal for crash lock boxes due to pre-break of crease 1+3
- High production output
- Low maintenance costs
- Designed for multi-shift operation
Highlights
Standard Equipment
- Feeder with vibrating device
- Infinitely adjustable distance between carton blanks
- Pre-breaking crease 1+3
- Bottom disc glue unit
- Electronic counter with digital display, including preset counter
- Delivery with kick-out device
- Drying and press section synchronised with machine speed, can be controlled separately
- Belt speed 150 m/min
Special Equipments
- Crash lock bottom device
- Upper nozzle gluing unit
- Bottom nozzle gluing unit
- Stripping unit for varnished cartons
- Attachment for Compact-Disc sleeves
- Special equipment for mini folding boxes
- Code reader, glue line detector
Unusual blank formats and special board qualities will be checked by us. Please avoid numerous extreme dimensions in one cardboard blank.
Result orientated perfection
Window styles
Technical Specifications
| Output | 150 m/min |
| Driving power | 3 kW |
| Power supply | 230 V/50 Hz or 60 Hz |
| Box types | Straight line Crash lock bottom Double wall CD/DVD-sleeves |
| Space requirements | approx. 5500 x 1200 mm |
| Weight | approx. 700 kg |
